Boiler Heating Batching Process Control System
Product Code : JA-AM-6478
The Boiler Heating Batching Process Control System (SKU JA-AM-6478) is a laboratory test stand with four control loops, each with its own local digital industrial controller, plus a further controller for cascade control, so that two cascade systems can be built. The controllers can be configured independently and run individually or together, and all have serial interfaces. Water circulates in a closed circuit, pumped from a supply tank by a 1.1 kW centrifugal pump through a pneumatic control valve. It is supplied by JaincoLab for process control laboratories.
Specifications
The stand has four local digital industrial controllers plus a cascade controller, all with serial interfaces, a closed water circuit with supply tank and 1.1 kW centrifugal pump, and a pneumatically actuated control valve; loop variables, heater rating and utilities are not listed in the product data and are confirmed on the quotation.
| Product | Boiler Heating Batching Process Control System |
| SKU | JA-AM-6478 |
| Control loops | 4, each with a local digital industrial controller |
| Cascade | 2 cascade systems possible; additional cascade controller |
| Interfaces | Serial interfaces on all controllers |
| Water circuit | Closed; supply tank; 1.1 kW centrifugal pump |
| Final control element | Pneumatically actuated control valve |
Experiments with the boiler heating batching control system
Students configure the four controllers, run loops singly or together, and set up cascade structures to study interacting heating and batching processes.
- Operating four independent control loops
- Building two cascade control systems
- Configuring industrial digital controllers
- Serial communication with controllers
- Process control practicals on heating and batching
Scope of supply
This listing covers the process control system with controllers, water circuit, pump and control valve as described. Accessories, spares and quantities are confirmed on the quotation. Compressed air, power supply and PC software are confirmed on the quotation.
Packing, MOQ and lead time
Packing, lead time and any minimum order for the Boiler Heating Batching Process Control System are confirmed per quotation according to order size and destination. Bulk orders for institutes are supplied, and export consignments to buyers in Africa, the Middle East and South and South-East Asia are quoted on request.
JaincoLab specialises in turnkey laboratory projects funded by education ministries, the World Bank and United Nations programmes, manufacturing and exporting the equipment and executing these projects successfully in many countries. Tender bidders can send their requirement list through our tenders page for a line-by-line quotation.
Frequently asked questions
How many control loops are there?
Four, each with a local digital industrial controller, plus a cascade controller.
Can cascade control be studied?
Yes, two cascade control systems can be realised.
What pump is used?
A 1.1 kW centrifugal pump in a closed water circuit.
What details are needed for a quote?
The SKU JA-AM-6478, the quantity required and the delivery destination; any detail not listed above is confirmed on the quotation.
