Triac Characteristics Apparatus
Product Code : JA-SCD-1097
The Triac Characteristics Apparatus (SKU JA-SCD-1097) is used to study the main-terminal (MT) characteristics of a Triac when a gate signal is applied. One Triac is mounted on the panel. A 0-25 V DC, 100 mA supply for the main terminals and a 0-5 V DC, 200 mA supply for the gate are built in, three round meters give the readings, and all connections are brought out to terminals.
Specifications
The listing gives these details:
| Product | Triac Characteristics Apparatus |
| SKU | JA-SCD-1097 |
| Device | One Triac, panel-mounted |
| DC supply 1 | 0-25 V, 100 mA |
| DC supply 2 | 0-5 V, 200 mA |
| Meters | Three round meters |
| Size | 15 x 8 x 4 in |
Scope of supply and ordering
One apparatus per order line. Quantities and packing are confirmed on the quotation.
Frequently asked questions
What does the Triac Characteristics Apparatus study?
The MT characteristics of a Triac with a gate signal applied.
What supplies are built in?
0-25 V DC at 100 mA and 0-5 V DC at 200 mA, with three round meters.
