Hall Effect Experiment
Product Code : JA-SCD-1091
The Hall Effect Experiment (SKU JA-SCD-1091) is a set-up for measuring the Hall voltage across a mounted germanium crystal placed in a magnetic field, from which the Hall coefficient and carrier type of the semiconductor are worked out. The field comes from a 7.5 kG electromagnet run from a 0-100 V, 4 A supply with meter, and is measured with a digital gauss meter (0-20 kG) and Hall probe. A constant current supply, 0-20 mA, drives the crystal, and two digital meters show the Hall voltage and crystal current.
Specifications
Parts and ratings from the listing:
| Product | Hall Effect Experiment |
| SKU | JA-SCD-1091 |
| Sample | Germanium crystal, mounted |
| Electromagnet | 7.5 kG |
| Electromagnet supply | 0-100 V, 4 A, with meter |
| Crystal supply | Constant current, 0-20 mA |
| Digital meters | Two: Hall voltage and crystal current |
| Gauss meter | Digital, 0-20 kG, with Hall probe |
Scope of supply and ordering
The listing covers the crystal, electromagnet with supply, constant current supply, digital meters and gauss meter. Quantities and packing are confirmed on the quotation.
Frequently asked questions
Which sample does the Hall Effect Experiment use?
A mounted germanium crystal.
How is the magnetic field produced and measured?
By a 7.5 kG electromagnet on a 0-100 V, 4 A supply, measured with a 0-20 kG digital gauss meter and Hall probe.
What current drives the crystal?
A constant current supply of 0-20 mA.
