Stirred Tank Test Stand
Product Code : JA-AM-6475
The Stirred Tank Test Stand (SKU JA-AM-6475) is a test stand for experiments on a multivariable system in which temperature and level in a stirred tank are controlled together. The double-walled tank is heated electrically, a pneumatic control valve sets the level through the product discharge, and a heat exchanger returns heat from the leaving product to the feed. The water circuit is closed. It is supplied by JaincoLab for advanced control engineering and chemical process laboratories.
Specifications
The stand has an electrically heated double-walled stirred tank, a feed-product heat exchanger, a pneumatic level control valve on the discharge, a closed water circuit and controllers with a Profibus DP interface; tank volume, heater power and utilities are not listed in the product data and are confirmed on the quotation.
| Product | Stirred Tank Test Stand |
| SKU | JA-AM-6475 |
| Controlled variables | Temperature and level in a stirred tank - interacting |
| Tank | Double-walled, electrically heated, stirred |
| Heat recovery | Heat exchanger from product to feed |
| Level control | Pneumatic control valve on product discharge |
| Water system | Closed circuit |
| Controllers | With Profibus DP interface for optional process control software |
Experiments with the stirred tank test stand
Students control tank temperature and level at the same time, see how heating and throughput interact through the heat exchanger, and tune the loops to limit that interaction.
- Simultaneous temperature and level control
- Interaction between thermal and hydraulic loops
- Heat recovery with a feed-product exchanger
- Pneumatic valve level control
- Advanced process control practicals
Scope of supply
This listing covers the stirred tank test stand as described. Accessories, spares and quantities are confirmed on the quotation. Optional monitoring software, compressed air and PC are confirmed on the quotation.
Packing, MOQ and lead time
Lead time, MOQ and packing are set on each quotation for the ordered quantity and delivery destination. The Stirred Tank Test Stand can be ordered for a single laboratory or as part of a complete laboratory package for a college or training programme.
Frequently asked questions
Which variables are controlled?
Temperature and level in a stirred tank.
How is the tank heated?
It is a double-walled tank heated electrically.
How is the level controlled?
By a pneumatic control valve on the product discharge.
What details are needed for a quote?
The SKU JA-AM-6475, the quantity required and the delivery destination; any detail not listed above is confirmed on the quotation.
