Rotary Dryer
Product Code : JA-AM-9189
The Rotary Dryer (SKU JA-AM-9189) is a chemical engineering unit for studying the drying of wet solids by hot air in a rotating shell. A long cylindrical shell, slightly inclined towards the outlet, turns slowly on a motor and reduction gearbox while internal flights lift the solids and shower them through air heated by a blower and heating chamber, flowing counter-current to the solids. It is supplied by JaincoLab for chemical engineering laboratories in colleges and polytechnics.
Specifications
The dryer has a revolving inclined cylindrical shell on two support brackets with internal flights, a motor and reduction gearbox drive, a blower with heating chamber, and flow control and bypass valves, needing 1.5 m x 2 m of floor space and a 1 phase, 220 V AC, 4 kW supply.
| Product | Rotary Dryer |
| SKU | JA-AM-9189 |
| Shell | Long revolving cylinder, slightly inclined to the outlet, on two brackets, with internal flights |
| Drive | Electric motor with reduction gearbox, low rpm |
| Hot air | Blower and heating chamber; counter-current to solids |
| Air control | Flow control and bypass valves |
| Floor space | 1.5 m x 2 m |
| Electricity | 1 phase, 220 V AC, 4 kW |
Experiments with the rotary dryer
Students feed wet solid at one end, run the shell with hot counter-current air and sample the dried product at the discharge to study drying characteristics and dryer operation.
- Drying characteristics of a solid under batch drying conditions
- Operation of a rotary dryer
- Effect of air flow and temperature on drying
- Heat and mass transfer in direct-contact drying
- Mass transfer and unit operations practicals
Scope of supply
This listing covers the rotary dryer with shell, drive, blower, heating chamber and valves as described. Accessories, spares and quantities are confirmed on the quotation. Shell dimensions and heater rating are confirmed on the quotation.
Packing, MOQ and lead time
Minimum order quantity, packing and lead time for the Rotary Dryer are stated on the quotation once the quantity and delivery destination are known. JaincoLab supplies single laboratory orders, bulk requirements for engineering colleges and polytechnics, and tender lots.
Frequently asked questions
How does the rotary dryer work?
Internal flights lift the wet solid and shower it through hot air flowing counter-current as the inclined shell rotates.
What utilities are required?
Floor space of 1.5 m x 2 m and a 1 phase, 220 V AC, 4 kW supply, plus the wet solid.
How is the air flow regulated?
With a flow control valve and a bypass valve.
What should a quotation request include?
Send SKU JA-AM-9189, the quantity and the delivery destination.
