Concrete Penetrometer, Spring Type
Product Code : JA-CT-9890
The Concrete Penetrometer, Spring Type (SKU JA-CT-9890) measures the penetration resistance of fresh concrete or mortar, used to follow setting. A cylindrical spring housing carries a plunger graduated in 1 kg divisions up to 60 kg, read against the top of the housing, with a penetration needle at the other end. Six needle points of 645, 323, 161, 65, 32 and 16 mm² allow the full range of stiffness to be covered. It comes in a carrying case. It is supplied by JaincoLab for concrete laboratories.
Specifications
The penetrometer has a spring housing with plunger graduated in 1 kg divisions to 60 kg and six needles of 645, 323, 161, 65, 32 and 16 mm², supplied in a carrying case.
| Product | Concrete Penetrometer, Spring Type |
| SKU | JA-CT-9890 |
| Capacity | 60 kg, 1 kg divisions |
| Construction | Cylindrical spring housing with graduated plunger |
| Needle points | Six: 645, 323, 161, 65, 32 and 16 mm² |
| Case | Carrying case |
Applications of the concrete penetrometer
Technicians push the needle into sieved mortar at intervals, read the force on the plunger scale and divide by the needle area to track penetration resistance as the concrete sets.
- Time of setting of concrete by penetration resistance
- Effect of admixtures on setting time
- Site checks on mortar stiffness
- Planning finishing operations
- Concrete technology practicals
Scope of supply and ordering
This listing covers the spring-type concrete penetrometer with six needles in a carrying case. Accessories, spares and quantities are confirmed on the quotation.
Packing, lead time and any minimum order for the Concrete Penetrometer, Spring Type are confirmed per quotation according to order size and destination. Bulk orders for institutes are supplied, and export consignments to buyers in Africa, the Middle East and South and South-East Asia are quoted on request.
Frequently asked questions
What is the maximum reading?
60 kg in 1 kg divisions.
Which needle sizes are supplied?
Six needles of 645, 323, 161, 65, 32 and 16 mm².
How is it carried?
In a carrying case.
