Core Case
Product Code : JA-CT-9894
The Core Case (SKU JA-CT-9894) is a hand-held concrete core drilling system for taking cores from slabs, walls and other members. A heavy-duty rotary electric drill connects to the core drill assembly through a flexible rubber coupling and produces cores up to 100 mm diameter without a separate frame and feed stand. A flanged water jacket around the core barrel clamps to the surface being drilled, and turning the capstan wheel with one hand keeps a steady feed pressure on the bit. It is supplied by JaincoLab for concrete testing laboratories and site teams.
Specifications
The system has a hand-held rotary drill on a flexible rubber coupling, a flanged water jacket that clamps to the surface and a capstan-wheel feed; it produces cores up to 100 mm diameter, other diameters need a conversion kit, and drill power is not listed in the product data and is confirmed on the quotation.
| Product | Core Case |
| SKU | JA-CT-9894 |
| Core size | Up to 100 mm diameter |
| Drill | Heavy-duty hand-held rotary electric drill |
| Coupling | Flexible rubber coupling to the core drill assembly |
| Water jacket | Flanged, clamps to the surface being drilled |
| Feed | Capstan wheel for steady pressure on the bit |
| Other diameters | Additional conversion kit |
Applications of the core drilling system
Operators clamp the water jacket to the member, feed water to the barrel and advance the bit with the capstan wheel to cut a core for strength testing or inspection.
- Taking concrete cores for compressive strength
- Cores for permeability and carbonation checks
- Investigating existing structures
- Checking slab and pavement thickness
- Concrete testing practicals
Scope of supply and ordering
This listing covers the Core Case hand-held core drilling system. Accessories, spares and quantities are confirmed on the quotation. Core bits in the sizes required and the conversion kit are confirmed on the quotation.
Packing, lead time and any minimum order for the Core Case are confirmed per quotation according to order size and destination. Bulk orders for institutes are supplied, and export consignments to buyers in Africa, the Middle East and South and South-East Asia are quoted on request.
Frequently asked questions
What core size can it drill?
Cores up to 100 mm in diameter.
Does it need a drilling frame?
No, the hand-held drill works without a separate frame and feed stand.
How is feed pressure applied?
By turning the capstan wheel with one hand.
Related products
More concrete testing apparatus is listed in the concrete testing equipment range from JaincoLab.
Request a quote
Send an enquiry for the Core Case (SKU JA-CT-9894) with the quantity and delivery destination using the JaincoLab contact page or by email to [email protected]. Buying under a laboratory tender? Use our tenders page.
