Water Current Meter Cup Type
Product Code : JA-STE-3424
The water current meter cup type (SKU JA-STE-3424) measures the velocity of water in rivers, canals and channels, from which discharge is calculated. The cup rotor turns on a spear pivot, and its revolutions are counted on a digital electronic counter. It is supplied with suspension parts, a 10 kg fish weight, wire rope and connection wire, and JaincoLab makes it for hydrology and irrigation engineering field work and teaching.
Specifications
The water current meter cup type has one spear pivot, a suspension flat about 30 cm long, a 120 cm suspension rod, a 10 m connection wire with clip, a 10 m wire rope with clip, a 10 kg fish weight, a spanner, a 30 ml oil can and a digital electronic counter.
| Product | Water Current Meter Cup Type |
| SKU | JA-STE-3424 |
| Pivot | One spear pivot |
| Suspension flat | About 30 cm long |
| Suspension rod | 120 cm long |
| Connection wire | 10 m, with clip |
| Wire rope | 10 m, with connecting clip |
| Fish weight | 10 kg |
| Counter | Digital electronic counter |
| Tools | Spanner wrench; oil can with 30 ml machine oil |
Applications of the cup type water current meter
The cup type water current meter is lowered into a stream on a rod or wire rope, and the rotor revolutions counted over a set time give the point velocity, which is combined across the section to find the discharge of the channel.
- Stream and river discharge measurement
- Velocity measurement in canals and channels
- Hydrology and irrigation engineering field work
- Water resources engineering practicals
- Flow gauging for surveys and projects
Scope of supply and ordering
The listing covers the cup type current meter with spear pivot, suspension flat and rod, connection wire, wire rope, fish weight, spanner, oil can, digital counter and other listed accessories. Rating table and carrying case are confirmed on the quotation with quantities.
MOQ, lead time and packing for the water current meter are confirmed on each quotation for the quantity and delivery destination. Single sets for departments and multiple sets for projects are supplied, including export to Africa, the Middle East and South and South-East Asia.
Frequently asked questions
How is the velocity read?
Rotor revolutions are counted on the digital electronic counter over a timed period and converted to velocity.
How is the meter suspended?
On the 120 cm suspension rod, or on the 10 m wire rope with the 10 kg fish weight for deeper water.
Which accessories are included?
Suspension flat and rod, connection wire, wire rope, fish weight, spanner, oil can and digital counter.
