Knurling Tool Holder
Product Code : JA-MMTM-8942
The knurling tool holder carries high-speed steel knurls for knurling turned work on the lathe. It is listed in two-knurl versions, generally fitted with medium knurls, and six-knurl versions with one pair each of fine, medium and coarse knurls, in holder sizes from 5/16 x 3/4 x 5 inch to 5/8 x 1-3/8 x 7-1/2 inch (SKU JA-MMTM-8942).
Specifications
Holder and knurl sizes from the listing:
| Product | Knurling Tool Holder |
| SKU | JA-MMTM-8942 |
| Knurls | High-speed steel |
| Two-knurl holders | Medium knurls as standard; other grades on request |
| Six-knurl holders | One pair each of fine, medium and coarse knurls |
| Holder sizes | 5/16 x 3/4 x 5, 3/8 x 7/8 x 5-1/2, 1/2 x 1-1/8 x 6-1/2 and 5/8 x 1-3/8 x 7-1/2 inch |
| Knurl dimensions | 5/8 inch dia x 5/16 inch thick, 7/32 inch hole (two smaller holders); 3/4 inch dia x 3/8 inch thick, 1/4 inch hole (two larger holders) |
| Pivot head holder | 1/2 x 1/2 x 4-1/2 inch, self-adjusting, 2 knurls |
| Single-knurl holder | 1/2 x 1/2 x 4-1/2 inch, 3/4 x 1/4 inch knurl |
| Finish | Shiny black |
Scope of supply and ordering
The listing covers one knurling tool holder of the item size and knurl count chosen, supplied by JaincoLab. The number of units, the packing and the dispatch time are confirmed on the quotation.
Frequently asked questions
Which knurls come with the six-knurl holder?
One pair each of fine, medium and coarse high-speed steel knurls.
Can the two-knurl holder have other knurls?
Yes, it is generally supplied with medium knurls but other grades can be provided on request.
Is there a self-adjusting version?
Yes, a 1/2 x 1/2 x 4-1/2 inch holder with a self-adjusting pivot head.
Related products
More items of this type are listed in the metal manufacturing training machine range.
Request a quote
Enquiries for the Knurling Tool Holder can be sent with the quantity needed through our contact page. Buying under a laboratory tender? Use our tenders page.
