Heat Exchanger Process Control System
Product Code : JA-AM-6479
The Heat Exchanger Process Control System (SKU JA-AM-6479) is a laboratory test stand that explains the basic terms of control engineering through a heat transfer process, using components common in industry. Water heated in a collector tank by an immersion heater is pumped through a heat exchanger; a second circuit with its own circulating pump carries the heat to a cooler with an electric fan. A universal controller drives a pneumatic flow control valve in the heater circuit and can also run cascade control. It is supplied by JaincoLab for process control laboratories.
Specifications
The stand has a collector tank with immersion heater, a heater-circuit pump, a heat exchanger, a second circuit with circulating pump and fan cooler, and a universal controller with a pneumatic flow control valve; heater power, flow ranges and utilities are not listed in the product data and are confirmed on the quotation.
| Product | Heat Exchanger Process Control System |
| SKU | JA-AM-6479 |
| Heater circuit | Collector tank with immersion heater; pump; pneumatic flow control valve |
| Heat exchanger | Between heater circuit and second circuit |
| Second circuit | Circulating pump; cooler with electric fan |
| Controller | Universal controller, all common configurations; cascade capable |
| Visualisation | Process visualisation software with fieldbus card (as listed) |
Experiments with the heat exchanger control system
Students control the heat transferred through the exchanger by adjusting the heater-circuit flow, compare controller configurations and set up a cascade loop.
- Basic control engineering terms on a thermal process
- Temperature control through a heat exchanger
- Comparing controller configurations
- Cascade control of temperature and flow
- Process control practicals
Scope of supply
This listing covers the heat exchanger process control stand with both circuits, cooler, controller and control valve. Accessories, spares and quantities are confirmed on the quotation. Visualisation software, compressed air and PC are confirmed on the quotation.
Packing, MOQ and lead time
Lead time, MOQ and packing are set on each quotation for the ordered quantity and delivery destination. The Heat Exchanger Process Control System can be ordered for a single laboratory or as part of a complete laboratory package for a college or training programme.
Frequently asked questions
How is heat supplied and removed?
An immersion heater warms the first circuit and a fan cooler removes heat from the second.
What does the controller adjust?
A pneumatic flow control valve in the heater circuit.
Can cascade control be studied?
Yes, the universal controller can also operate as a cascade controller.
How do I request a price?
Share the SKU JA-AM-6479, the quantity and the delivery destination through the contact page or by email to [email protected].
