Drying Oven
Product Code : JA-CL-8859
The drying oven is a 225-litre forced-air oven for drying large quantities of aggregate and soil samples, with a temperature range of 50 to 300 °C. A microcomputer PID controller with digital display and timer sets the temperature, and a blower fan circulates hot air through the chamber (SKU JA-CL-8859).
Specifications
Oven specification from the listing:
| Product | Drying Oven |
| SKU | JA-CL-8859 |
| Capacity | 225 litres |
| Temperature range | 50 to 300 °C |
| Temperature resolution | 0.1 °C |
| Temperature fluctuation | ±0.75 °C |
| Heater power | 2.5 kW |
| Timer range | 1 to 9999 min |
| Controller | Microcomputer PID with digital display, timer and temperature control protection |
| Air circulation | Blower fan and air channels; blast and exhaust adjustable on the control panel |
| Interior | Stainless steel, argon-arc welded |
| Exterior | Steel sheet |
| Door | Silicone gasket and transparent thermal glass window |
| Shelves | 3, with 4 shelf positions |
Uses in the concrete and soil lab
- Drying large quantities of aggregate samples
- Drying large quantities of soil samples
Scope of supply and ordering
The listing covers one 225-litre drying oven with three shelves, supplied by JaincoLab. The quotation states the packing, the lead time and the number of units.
Frequently asked questions
What temperature range does the oven cover?
50 to 300 °C, with 0.1 °C resolution and ±0.75 °C fluctuation.
How many shelves are fitted?
Three shelves, with four shelf positions.
Can the samples be seen during drying?
Yes, the door has a transparent thermal glass window and a silicone gasket.
