Cavitation Demonstration
Product Code : JA-HAP-8930
The cavitation demonstration is a small-scale apparatus that shows cavitation in a circular venturi-shaped section of clear acrylic, using water from a hydraulics bench. Flow control valves upstream and downstream set the flow conditions, and three Bourdon gauges show the static pressure before the contraction, in the throat and after the expansion (SKU JA-HAP-8930).
Specifications
Gauges and fittings as listed:
| Product | Cavitation Demonstration |
| SKU | JA-HAP-8930 |
| Test section | Circular venturi shape, clear acrylic |
| Flow control | Valves upstream and downstream of the test section |
| Upstream gauge | 63 mm dia, 0 to 1 bar |
| Throat vacuum gauge | 100 mm dia, -1 to 0 bar |
| Downstream gauge | 63 mm dia, 0 to 1 bar |
| Connection | Quick release fitting to the hydraulics bench |
| Stand-alone use | Visualisation only, from a cold water mains supply of 0.4 litres/s at 2 bar gauge |
| Software | Educational software available as an option |
Scope of supply and ordering
The listing covers the acrylic venturi section with its valves, three gauges and bench fitting, supplied by JaincoLab; the educational software is optional. Packing, lead time and the quantity per order are agreed on the quotation.
Frequently asked questions
What range does the throat gauge read?
-1 to 0 bar, on a 100 mm vacuum gauge.
Can it be used without a hydraulics bench?
For visualisation only, from a cold water mains supply giving 0.4 litres/s at 2 bar gauge.
What is the test section made of?
Clear acrylic, in a circular venturi shape.
Related products
More items of this type are listed in the hydraulics and pneumatics range.
Request a quote
To order the Cavitation Demonstration, send the SKU JA-HAP-8930, the quantity and the delivery destination through the JaincoLab contact page. Buying under a laboratory tender? Use our tenders page.
