Acrylic Heat Exchanger Circulation Trainer
Product Code : JA-AM-5948
The Acrylic Heat Exchanger Circulation Trainer (SKU JA-AM-5948) is a training unit for showing how fluids circulate through a heat exchanger, supplied by JaincoLab for process engineering teaching. Built in acrylic, a heat exchanger trainer of this kind lets learners watch the shell-side and tube-side flows and understand how the two streams exchange heat without mixing.
Specifications
The saved listing gives only the product name, so the exchanger type, circulation system, dimensions and utility needs are confirmed on the quotation.
| Product | Acrylic Heat Exchanger Circulation Trainer |
| SKU | JA-AM-5948 |
| Construction | Acrylic (as named) |
| Subject | Heat exchanger circulation |
| Specification | Exchanger type, size and utilities confirmed on the quotation |
Applications of the heat exchanger trainer
The trainer is used to visualise flow paths in a heat exchanger and to explain counter-current and co-current flow, baffles and passes before trainees work with metal exchangers on plant.
- Heat transfer lessons in chemical and mechanical engineering
- Process operator training
- Polytechnic unit-operations laboratories
- Refinery training centres
Scope of supply and ordering
The listing covers one Acrylic Heat Exchanger Circulation Trainer as described above, supplied by JaincoLab. Dimensions, materials beyond those stated and utility requirements are confirmed on the quotation. Accessories, spares and quantities are confirmed on the quotation.
Minimum order quantity, lead time and packing for the Acrylic Heat Exchanger Circulation Trainer are confirmed on each quotation according to the quantity and the delivery destination. JaincoLab supplies single units for a department as well as bulk orders for schools, colleges and training institutes.
Frequently asked questions
What does the trainer show?
Fluid circulation through a heat exchanger, in acrylic for visibility.
What exchanger type and size is it?
These are confirmed on the quotation.
Who uses these acrylic process models?
Chemical engineering departments, polytechnics and refinery or process-plant training centres.
