Verification of Network Theorems
Product Code : JA-VONT-1127
The Verification of Network Theorems apparatus (SKU JA-VONT-1127) covers four DC circuit theorems on a single panel: superposition, Norton's theorem, Thevenin's theorem and maximum power transfer. Three fixed-output DC power supplies of 12 V and 5 V at 100 mA and four moving coil meters are built in. The circuit diagram of each theorem is printed on the front panel, and the supplies, meters, resistances and potentiometers are brought out to terminals.
Specifications
Supplies, meters and panel layout as listed:
| Product | Verification of Network Theorems |
| SKU | JA-VONT-1127 |
| Theorems | Superposition, Norton, Thevenin, maximum power transfer |
| Power supplies | Three fixed-output DC, 12 V and 5 V at 100 mA |
| Meters | Four moving coil meters |
| Panel | Circuit diagrams of all four theorems printed on the front |
| Connections | Supplies, meters, resistances and potentiometers on terminals |
Scope of supply and ordering
One apparatus covers all four theorems, with supplies and meters built in. Patch leads, quantities and packing are confirmed on the quotation.
Frequently asked questions
Which theorems can be verified on this apparatus?
Superposition, Norton's, Thevenin's and maximum power transfer.
What supplies and meters are built in?
Three fixed DC supplies of 12 V and 5 V at 100 mA and four moving coil meters.
Related products
- Verification of Superposition Theorem
- Verification of Nortons and Thevenins Theorems
- Verification of Reciprocity Theorem
- Verification of Maximum Power Transfer Theorem in DC Circuits
Single-theorem versions are listed in our scientific instrument range.
Request a quote
To order the network theorems apparatus, give the quantity on our contact page. Institutions and contractors buying under a tender can also reach us via the tenders page.
