Ventilation Trainer
Product Code : JA-ELA-5452
The Ventilation Trainer (SKU JA-ELA-5452), supplied by JaincoLab, is designed for training in ventilation engineering. Trainees first build a ventilation system themselves, then investigate how bends, branches and regulator flaps affect the airflow rate, the air velocity and the pressure loss. The components are the same as those used in real ventilation installations, and each is fitted with pressure measuring glands.
Specifications
Measurements are taken with an inclined tube manometer with two measuring ranges and a digital handheld air velocity meter, while a voltmeter and ammeter on the switch cabinet show the fan power consumption.
| Product | Ventilation Trainer |
| SKU | JA-ELA-5452 |
| Purpose | Building and testing ventilation duct systems |
| Components | Standard ventilation engineering parts, fitted with pressure measuring glands |
| Pressure measurement | Inclined tube manometer, 2 measuring ranges |
| Air velocity | Digital handheld measuring unit |
| Fan power | Voltmeter and ammeter on the switch cabinet |
Experiments with the ventilation trainer
- Pressure loss across bends and branches
- Effect of regulator flaps on airflow rate
- Air velocity measurement in ducts
- Fan power consumption at different settings
Scope of supply and ordering
The listing covers the trainer with its duct components, manometer, velocity meter and switch cabinet; electrical supply, quantity and lead time are confirmed on the quotation.
Frequently asked questions
What can be investigated?
The effect of bends, branches and regulator flaps on airflow rate, air velocity and pressure loss.
Which instruments are included?
An inclined tube manometer with two ranges, a digital handheld air velocity meter, and a voltmeter and ammeter for fan power.
Do trainees assemble the system?
Yes. The ventilation system is built by the trainee before the measurements are made.
