Training Board for Triac
Product Code : JA-AET-1461
The TRIAC training board is used to study the gate characteristics of a TRIAC in modes I+, I-, III+ and III-, its terminal characteristics in modes I+ and III+, and its holding current. It also demonstrates the TRIAC as a static switch under DC control and the control of AC with an AC signal, using built-in 0-70 V and 0-3 V DC regulated supplies and 55 V and 7 V AC supplies (SKU JA-AET-1461).
Specifications
Parts and ratings built into the TRIAC board:
| Product | Training Board for Triac |
| SKU | JA-AET-1461 |
| DC supplies | 0-70 V DC at 100 mA and 0-3 V DC at 30 mA, regulated |
| AC supplies | 55 V at 100 mA and 7 V at 30 mA, fixed |
| Device | TRIAC |
| Controls | Three potentiometers; reset switch |
| Mains | 230 V ±10%, 50 Hz AC; ON/OFF switch, fuse and jewel light |
| Patch cords | 4 mm spring-loaded plugs, stackable from the rear at both ends, 0.5 m |
| Other apparatus required | CRO 20 MHz; digital DC current meters (20 mA / 200 mA and 200 mA ranges); digital DC voltmeter (2 V / 200 V) |
TRIAC studies
The listed experiments are:
- Gate characteristics in modes I+, I-, III+ and III- (T2 and gate polarity with respect to T1)
- Terminal characteristics in modes I+ and III+
- TRIAC as a static switch (DC control)
- Control of AC with an AC signal
- Holding current (IH) measurement
Scope of supply and ordering
The listing covers the TRIAC training board with patch cords and operating instructions, supplied by JaincoLab; the meters and oscilloscope are listed as other apparatus required. Pack quantities, packing method and lead time are fixed on the quotation.
Frequently asked questions
Which TRIAC modes are covered?
Gate characteristics in modes I+, I-, III+ and III-, and terminal characteristics in modes I+ and III+.
What applications does the board demonstrate?
The TRIAC as a static switch under DC control and the control of AC with an AC signal.
Are meters built in?
No. Digital DC current meters, a digital DC voltmeter and a 20 MHz oscilloscope are listed as other apparatus required.
