Study of Operational Amplifier as Sine to Square Wave Converter
Product Code : JA-COA-1141
The Study of Operational Amplifier as Sine to Square Wave Converter apparatus (SKU JA-COA-1141) turns a sine wave into a square wave with a zero-crossing detector. The circuit is a single-supply comparator: the sinusoidal input, with peaks of -5 V and +5 V, is first shifted by a voltage divider to a 0 V to 5 V sinusoid, and the comparator then switches its output each time the signal crosses the reference.
Specifications
Circuit details from the product data:
| Product | Study of Operational Amplifier as Sine to Square Wave Converter |
| SKU | JA-COA-1141 |
| Circuit | Single-supply comparator used as a zero-crossing detector |
| Input signal | Sine wave, -5 V and +5 V peaks |
| Signal conditioning | Voltage divider shifts the input to 0 V to 5 V |
| Output | Square wave |
Scope of supply and ordering
Supply, signal source and CRO requirements are confirmed on the quotation together with quantities and packing.
Frequently asked questions
How does the apparatus convert a sine wave to a square wave?
A single-supply comparator acts as a zero-crossing detector and switches at each crossing.
Why is a voltage divider used at the input?
It shifts the -5 V to +5 V sine input to a 0 V to 5 V signal for the single-supply comparator.
