My Temp Heating and Cooling Incubator
Product Code : JA-LE-8193
The My Temp Heating and Cooling Incubator (SKU JA-LE-8193) is a floor-standing heating and cooling incubator with a 65 litre stainless steel chamber, controlled from 0 to 60°C. Forced air spreads heat evenly through the chamber, and for sub-ambient settings a compressor cools it to the set point. A large display shows chamber temperature and remaining incubation time. It is supplied by JaincoLab.
Specifications
Chamber, control and service values listed for the incubator:
| Product | My Temp Heating and Cooling Incubator |
| SKU | JA-LE-8193 |
| Temperature range | 0 to 60°C (RT -25°C to 60°C) |
| Accuracy / uniformity | 0.5°C / +/-1.0°C (at 37°C) |
| Setting step | 0.1°C |
| Capacity | 65 L (2.3 cu ft); 30 BOD bottles of 300 ml |
| Interior (w x d x h) | 40 x 32.4 x 50.2 cm, stainless steel |
| Exterior (w x d x h) | 54 x 53.3 x 99.9 cm (floor-standing) |
| Weight | 53 kg |
| Refrigerant | R134A |
| Electrical | 120 V 60 Hz or 230 V 50 Hz, 385 W |
| Ambient operating range | +10 to +30°C |
| Fittings | Two height-adjustable shelves, internal light, internal power outlet |
Uses of the heating and cooling incubator
Because it both heats and cools, it covers:
- Incubation below and above room temperature in one cabinet
- BOD bottle incubation, with room for 30 bottles of 300 ml
- Running small shakers or rockers inside the chamber from the internal outlet
Scope of supply and ordering
The incubator comes with two adjustable shelves; extra shelves can be ordered, so give the number you need with the quantity and site voltage, and the quotation will list packing and lead time.
Frequently asked questions
How does the incubator reach temperatures below ambient?
When a sub-ambient temperature is set, the compressor switches on and cools the chamber quickly to the set point.
How many BOD bottles does the chamber hold?
The 65 L chamber holds 30 BOD bottles of 300 ml.
Can other instruments run inside it?
Yes, a built-in internal outlet powers small instruments such as shakers and rockers.
Related products
- MyTemp Mini Digital Incubator
- My Temp Mini CO2 Digital Incubator
- Incu Shaker 10L and 10LR
- Incu Shaker Mini with Flat Mat Platform
Incubators of other sizes are in our laboratory equipment range.
Request a quote
Ask for the price of the My Temp Heating and Cooling Incubator on our contact page. Tender and project enquiries can be sent through the tenders page.
