Large Pull Out Test Apparatus for Geo Synthetics
Product Code : JA-GT-9866
The Large Pull Out Test Apparatus for Geo Synthetics (SKU JA-GT-9866) finds the pull-out interface properties of geogrids and other reinforcement in soil, including the interfacial friction between GI strips or geosynthetics and soil. The interfacial friction coefficient is a key design parameter for reinforced earth walls, reinforced slopes and other reinforcement applications. This large pull-out test apparatus is supplied by JaincoLab for geosynthetics and geotechnical engineering laboratories.
Specifications
The product data describes the purpose of the apparatus; box size, pull-out force capacity, normal load system and displacement measurement are not listed in the product data and are confirmed on the quotation.
| Product | Large Pull Out Test Apparatus for Geo Synthetics |
| SKU | JA-GT-9866 |
| Test | Pull-out of reinforcement from soil |
| Materials | Geogrids, geosynthetics and GI strips |
| Result | Interfacial friction coefficient and pull-out interface properties |
Experiments with the pull-out test apparatus
Students embed a geogrid or strip in compacted soil under a normal load and pull it out at a set rate, recording force and displacement to find the interface friction.
- Pull-out resistance of geogrids in soil
- Interfacial friction of GI strips and geosynthetics
- Design data for reinforced earth walls and slopes
- Comparing reinforcement products
- Geotechnical research and teaching
Scope of supply and ordering
This listing covers the large pull-out test apparatus as described. Accessories, spares and quantities are confirmed on the quotation. Loading, force measurement and displacement gauges are confirmed on the quotation.
Packing, lead time and any minimum order for the Large Pull Out Test Apparatus for Geo Synthetics are confirmed per quotation according to order size and destination. Bulk orders for institutes are supplied, and export consignments to buyers in Africa, the Middle East and South and South-East Asia are quoted on request.
Frequently asked questions
What does the test find?
The pull-out interface properties and friction coefficient of reinforcement in soil.
Which materials can be tested?
Geogrids, geosynthetics and GI strips.
Why is it important?
The interfacial friction coefficient is a key parameter for reinforced earth wall and slope design.
