Cross Permeability Test Apparatus
Product Code : JA-GT-9860
The Cross Permeability Test Apparatus (SKU JA-GT-9860) measures the permeability of a geotextile across its plane - the volumetric flow of water per unit area under unit hydraulic head. It provides both constant head and falling head permeameters; the constant head test uses a 50 mm head of water on a 100 mm diameter specimen. A geotextile must be much more permeable than the soil it protects, so water passes without building up pressure. It is supplied by JaincoLab for geosynthetics and civil engineering laboratories.
Specifications
The apparatus includes constant head and falling head permeameters for 100 mm diameter specimens, with a 50 mm water head for the constant head test; permeameter construction and accessories are not listed in the product data and are confirmed on the quotation.
| Product | Cross Permeability Test Apparatus |
| SKU | JA-GT-9860 |
| Tests | Constant head and falling head cross-plane permeability |
| Specimen diameter | 100 mm |
| Constant head | 50 mm of water |
| Property | Volumetric flow per unit area under unit hydraulic head |
Experiments with the cross permeability apparatus
Students clamp a geotextile disc in the permeameter, run constant head or falling head tests and calculate the permeability normal to the fabric plane.
- Cross-plane permeability of geotextiles
- Comparing constant head and falling head results
- Selecting filter fabrics for drainage
- Checking fabric permeability against soil permeability
- Geosynthetics practicals
Scope of supply and ordering
This listing covers the cross permeability apparatus with constant head and falling head permeameters. Accessories, spares and quantities are confirmed on the quotation. Water supply and measuring cylinders are confirmed on the quotation.
MOQ, lead time and packing for the Cross Permeability Test Apparatus are confirmed on each quotation for the quantity and delivery destination. Single units for one laboratory and complete sets for institutions or projects are both supplied.
Frequently asked questions
Which test methods are provided?
Both constant head and falling head permeameters.
What specimen size is used?
100 mm diameter.
What head is used for the constant head test?
50 mm of water.
