Interface Friction Measurement Apparatus
Product Code : JA-GT-9865
The Interface Friction Measurement Apparatus (SKU JA-GT-9865) evaluates both the frictional resistance and the pull-out resistance of soil reinforcing materials at the shear rate and drainage condition chosen by the designer. It uses 60 x 60 x 25 mm assemblies suitable for soils with D85 not greater than 4.75 mm. Soil reinforcement is used to improve soil behaviour in retaining structures, slopes, landslide protection and pavements. It is supplied by JaincoLab for geosynthetics and geotechnical laboratories.
Specifications
The apparatus uses 60 x 60 x 25 mm shear assemblies for soils with D85 up to 4.75 mm, testing friction with the reinforcement clamped in the plane of shear and pull-out resistance; loading frame and proving rings are not listed in the product data and are confirmed on the quotation.
| Product | Interface Friction Measurement Apparatus |
| SKU | JA-GT-9865 |
| Tests | Interface friction and pull-out resistance of soil reinforcement |
| Assembly size | 60 x 60 x 25 mm |
| Soil limit | D85 not greater than 4.75 mm |
| Conditions | Shear rate and drainage as specified by the designer |
Experiments with the interface friction apparatus
Students shear soil against a clamped reinforcement sample and pull reinforcement out of confined soil to find the interface friction angle and pull-out resistance.
- Soil-geosynthetic interface friction
- Pull-out resistance of reinforcement
- Design data for reinforced earth walls and slopes
- Comparing reinforcement materials
- Geotechnical practicals
Scope of supply and ordering
This listing covers the interface friction measurement apparatus with 60 x 60 x 25 mm assemblies. Accessories, spares and quantities are confirmed on the quotation. Shear machine, load measurement and dial gauges are confirmed on the quotation.
Minimum order quantity, packing and lead time for the Interface Friction Measurement Apparatus are stated on the quotation once the quantity and delivery destination are known. JaincoLab supplies single laboratory orders, bulk requirements for engineering colleges and polytechnics, and tender lots.
Frequently asked questions
What does the apparatus measure?
The frictional and pull-out resistance of soil reinforcing materials.
What assembly size is used?
60 x 60 x 25 mm.
Which soils are suitable?
Soils with D85 not greater than 4.75 mm.
