Inclined Ore Microscope
Product Code : JA-M-999
The Inclined Ore Microscope (SKU JA-M-999) is built for ore mineralogy, with a vertical illuminator for polished opaque sections and a sub-stage illuminator for transmitted light. A polariser, analyser and Bertrand lens work with the circular graduated stage, a variable transformer controls the light, and a straight tube is provided for photomicrography. Geology and mining engineering departments use this inclined ore microscope where students also need to record images of ore textures.
Specifications
The listing gives precise coarse and fine motion, a circular graduated stage with polariser, analyser and Bertrand lens, a vertical illuminator, a straight tube for photomicrography, a special sub-stage illuminator with variable light control transformer, objectives 4x, 10x and 40x and eyepieces WF10x, H5x with cross and H10x micro.
| Product | Inclined Ore Microscope |
| SKU | JA-M-999 |
| Focusing | Precise coarse and fine motion system |
| Stage | Circular, graduated |
| Polarising parts | Polariser, analyser and Bertrand lens |
| Illumination | Vertical illuminator; special sub-stage illuminator; variable light control transformer |
| Photomicrography | Straight tube |
| Objectives | 4x, 10x, 40x |
| Eyepieces | WF10x; H5x with cross; H10x micro |
| Storage | Optics supplied in a storing cabinet |
Applications of the inclined ore microscope
With both reflected and transmitted light and a photomicrography tube, the inclined ore microscope lets students identify opaque ore minerals in polished section, study the surrounding silicate minerals in thin section and photograph textures for practical records.
- Ore mineral identification in polished sections
- Transmitted polarised light study of thin sections
- Photomicrography of ore textures
- Economic geology and mining engineering practicals
- Mineral processing and metallurgy courses
Scope of supply and ordering
One unit is one inclined ore microscope with the listed stage, polarising parts, illuminators, transformer, photo tube, three objectives and three eyepieces in a storage cabinet. Camera, spares and quantities are confirmed on the quotation.
Each quotation states the minimum order quantity, the lead time and the packing for the quantity requested and the destination. JaincoLab handles bulk school and college orders and tender supplies, and ships to buyers in Africa, the Middle East and South and South-East Asia.
Frequently asked questions
Can photographs be taken?
A straight tube for photomicrography is listed; the camera and adapter are confirmed on the quotation.
How is the light controlled?
A variable light control transformer is listed with the sub-stage illuminator.
Which eyepieces are included?
WF10x, H5x with cross-lines and H10x micrometer eyepieces.
