Geotechnical Gauge
Product Code : JA-SM-8880
The geotechnical gauge is a water-resistant 127 x 203 mm (5 x 8 inch) plastic card on a lanyard for describing and classifying soils. It sorts coarse and fine-grained soils into fifteen descriptive categories under the Unified Soil Classification System, using six colour chips, four patches of sized grains and four tables (SKU JA-SM-8880).
Specifications
Card details as listed:
| Product | Geotechnical Gauge |
| SKU | JA-SM-8880 |
| Format | Water-resistant plastic card on a lanyard |
| Size | 127 x 203 mm (5 x 8 inch) |
| Classification | Coarse and fine-grained soils into 15 descriptive categories, gravels and sands to silts and clays |
| System | Unified Soil Classification System, by particle size |
| Aids | 6 colour chips; 4 patches of sized grains; 4 tables |
| Density and consistency | Sand from very loose to very dense; clay from very soft to hard |
| Scales | 0-6 inch and 0-110 mm on the card edges |
Scope of supply and ordering
The listing covers one geotechnical gauge card with lanyard, supplied by JaincoLab. Quantities, packing and lead time are confirmed on the quotation.
Frequently asked questions
Which classification system does it follow?
The Unified Soil Classification System, by particle size.
What scales are printed on it?
0-6 inch and 0-110 mm scales along the edges of the card.
How many soil categories does it cover?
Fifteen descriptive categories, from gravels and sands to silts and clays.
