Field CBR Equipment
Product Code : JA-SM-8861
The field CBR equipment measures the bearing capacity of soil in place, using a 50 kN field CBR jack to push a 50 mm penetration piston into the soil. Load is read on one of three proving rings of 10, 28 or 50 kN, and penetration on a dial gauge carried on a 2-metre bridge support (SKU JA-SM-8861).
Specifications
Parts and capacities as listed:
| Product | Field CBR Equipment |
| SKU | JA-SM-8861 |
| Use | Measuring soil bearing capacity in the field |
| Field CBR jack | 50 kN capacity, 8.5 kg, 254 mm total height |
| Proving rings | 10 kN, 28 kN and 50 kN |
| Penetration piston | 50 mm dia, threaded at the upper end |
| Extension rods | Steel tubing: 2 x 5 cm, 2 x 10 cm, 1 x 30 cm, 1 x 50 cm, 1 x 100 cm |
| Surcharge weights | Circular 4.54 kg (250 mm dia, 53 mm hole); slotted 4.54 kg and 9.07 kg (215-250 mm dia, 53 mm slot) |
| Bridge and dial support | 2 m bridge; seamless pipe dial support 30 cm high, 45 cm base, quick release sliding clamp |
| Other parts | Ball seating attachment; bracket and adapter; penetration dial indicator |
| Accessory | Dial gauge 0.01 mm x 25 mm |
Scope of supply and ordering
The listing covers the field CBR jack, three proving rings, piston, extension rods, surcharge weights, bridge support and dial fittings, supplied by JaincoLab. Pack quantities, packing method and lead time are fixed on the quotation.
