Diode Valve Characteristics Apparatus
Product Code : JA-COVT-1071
The Diode Valve Characteristics Apparatus (SKU JA-COVT-1071) is used to plot the V-I characteristics of a diode valve. A regulated 0-300 V DC supply at 30 mA provides the anode voltage and a 6.3 V AC, 1 A supply heats the filament. Two meters read voltage and current, and the panel carries a printed valve diagram with the supply and valve connections brought out to terminals.
Specifications
The listing gives these details:
| Product | Diode Valve Characteristics Apparatus |
| SKU | JA-COVT-1071 |
| DC supply | 0-300 V, 30 mA, regulated |
| Filament supply | 6.3 V AC, 1 A |
| Meters | Two, voltage and current |
| Panel | Printed valve diagram, connections on terminals |
| Size | 10 x 8 x 4 in |
Scope of supply and ordering
One apparatus with its valve per order line. Quantities and packing are confirmed on the quotation.
Frequently asked questions
What does the Diode Valve Characteristics Apparatus plot?
The V-I characteristics of a diode valve.
What supplies are built in?
A regulated 0-300 V DC, 30 mA supply and a 6.3 V AC, 1 A filament supply.
