Combined Convection and Radiation
Product Code : JA-HTLE-9207
The Combined Convection and Radiation accessory (SKU JA-HTLE-9207), supplied by JaincoLab, introduces students to heat loss by convection and radiation together from a heated horizontal cylinder. The cylinder sits in a vertical air duct with a fan at its base, so the air flow over it can be varied. This combined convection and radiation apparatus measures air and surface temperatures with K-type thermocouples and the air speed with a vane anemometer in the outlet duct.
Specifications
The combined convection and radiation unit is specified by a 100 W, 24 V DC heater in the cylinder, a variable air flow of 0 to 7 m/s on the computer-controlled version (manual on the other), K-type thermocouples and a vane-type anemometer. The service unit it connects to is quoted separately.
| Product | Combined Convection and Radiation |
| SKU | JA-HTLE-9207 |
| Test piece | Heated horizontal cylinder in a vertical air duct |
| Heater rating | 100 W at 24 V DC |
| Air flow | Fan at the base of the duct; 0 - 7 m/s electronically adjustable on the computer-controlled unit, manual otherwise |
| Temperature sensors | K-type thermocouples for upstream air and cylinder surface |
| Air flow measurement | Vane-type anemometer in the outlet duct |
| Mounting | PVC baseplate; tool-free connection to the heat transfer service unit |
Experiments with the combined convection and radiation apparatus
The accessory is used to separate and compare the convective and radiative heat losses from a hot cylinder as the air speed over it changes from still air to forced flow.
- Heat loss from a cylinder by combined free convection and radiation
- Effect of air velocity on forced convection from a cylinder
- Separating radiation and convection losses
- Comparing results with standard cylinder correlations
Scope of supply and ordering
The listing covers the Combined Convection and Radiation accessory. The heat transfer service unit, and computer control where required, are quoted separately. Accessories, spares and quantities are confirmed on the quotation.
MOQ, lead time and packing are confirmed on each quotation for the quantity and the delivery destination. Single set-ups and complete heat transfer laboratories for engineering colleges, polytechnics and ITIs, including tender orders, are supplied.
Frequently asked questions
What air speeds can be set?
0 to 7 m/s on the computer-controlled version; the air flow is set manually on the other version.
What is the heater rating?
100 W at 24 V DC.
How is air speed measured?
With a vane-type anemometer in the outlet duct.
