Tracing Table
Product Code : JA-SE-8845
The tracing table (SKU JA-SE-8845) is a light table for tracing maps, plans and drawings. It is made as a wooden or metal box whose upper face is covered with a translucent plastic surface, lit from inside by a bulb or fluorescent lamp so that lines on the lower sheet show through the tracing sheet. JaincoLab makes the tracing table for drawing offices and surveying and geography laboratories.
Specifications
The tracing table is a wooden or metallic box with a translucent plastic top surface illuminated from inside by a bulb or a fluorescent lamp; working area, lamp rating and power supply are confirmed on the quotation.
| Product | Tracing Table |
| SKU | JA-SE-8845 |
| Use | Tracing maps, plans and drawings |
| Body | Wooden or metallic box |
| Top surface | Translucent plastic |
| Illumination | Internal bulb or fluorescent lamp |
| Size and lamp rating | Confirmed on the quotation |
Applications of the tracing table
The tracing table is used to copy, compare and correct drawings by placing an original under a tracing sheet on the lit surface, which is common in map work, plan preparation and drawing practicals.
- Tracing maps and survey plans
- Copying and correcting engineering drawings
- Overlaying and comparing map sheets
- Drawing office and surveying laboratory work
- Geography and civil engineering practicals
Scope of supply and ordering
The listing covers the tracing table with its wooden or metal body, translucent plastic top and internal lamp. Working area, lamp type and rating, power supply and quantities are confirmed on the quotation.
MOQ, lead time and packing for the tracing table are confirmed on each quotation for the size, quantity and delivery destination. Single tables and sets for drawing offices and laboratories are supplied, with export to Africa, the Middle East and South and South-East Asia.
Frequently asked questions
How is the tracing surface lit?
By a bulb or fluorescent lamp inside the box, under a translucent plastic top.
Which body materials are available?
Wooden or metallic boxes; your choice is confirmed on the quotation.
What size is the working area?
The size is not listed; state the drawing sizes you work with and it is confirmed on the quotation.
Related products
Mapping and survey instruments are listed in the JaincoLab survey equipment range.
Request a quote
To order the tracing table, send the quantity and delivery destination through the JaincoLab contact page or email [email protected]. Tender and project enquiries can be sent through the tenders page.
