TDS Meter Bench Top
Product Code : JA-LS-4965
The TDS Meter Bench Top (SKU JA-LS-4965) is a battery-powered meter supplied by JaincoLab for measuring the conductivity, total dissolved solids and salinity of aqueous solutions. It reads on a 3½ digit LCD in two ranges, 0-2000 ppm and 0-20 ppt, using a platinum dip cell at a measuring frequency of 1000 Hz, with a stated accuracy of ±1% of full scale.
Specifications
The technical data given in the listing are shown below.
| Product | TDS Meter Bench Top |
| SKU | JA-LS-4965 |
| Measures | Conductivity, TDS and salinity of aqueous solutions |
| Display | 3½ digit LCD |
| Ranges | 0-2000 ppm; 0-20 ppt |
| Temperature compensation | Not provided |
| Cell constant adjustment | Pre-adjustable |
| Conductivity cell | Platinum dip cell |
| Measuring frequency | 1000 Hz |
| Accuracy | ±1% of full scale |
| Power | 1 x 9 V battery |
| Dimensions | 85 x 28 x 165 mm |
| Weight | About 0.8 kg |
Where it is used
A TDS meter works by measuring the electrical conductivity of the water, which rises with the amount of dissolved salts it contains:
- Checking drinking and process water for dissolved solids
- Salinity measurements in environmental science practicals
- Conductivity experiments in chemistry laboratories
- Monitoring water from stills and deionisers in the laboratory
Scope of supply and ordering
The meter is supplied by JaincoLab with its conductivity cell; quantities and packing are confirmed on the quotation.
Frequently asked questions
Which ranges does it have?
0-2000 ppm and 0-20 ppt.
Does it compensate for temperature?
No. Temperature compensation is not provided, so readings are best taken at a known temperature.
What kind of cell does it use?
A platinum dip-type conductivity cell, with a pre-adjustable cell constant.
How large is the meter?
85 x 28 x 165 mm, weighing about 0.8 kg, and it runs on one 9 V battery.
Related products
Water testing and general laboratory items are in the JaincoLab lab supplies range.
Request a quote
Request a quotation for the TDS Meter Bench Top (JA-LS-4965) through our contact page. Tender and project enquiries can be sent through the tenders page.
