Portable Circular Saw
Product Code : JA-WWM-8668
The portable circular saw is a hand-held saw for straight cuts in timber and boards in carpentry training workshops. It has a 1.6 kW single-phase 220 V, 50 Hz motor running at 4000 rpm with a 210 mm blade, cuts up to 70 mm deep at 90° and 45 mm at 45°, and comes with three blades and English manuals (SKU JA-WWM-8668).
Specifications
Listed specification:
| Product | Portable Circular Saw |
| SKU | JA-WWM-8668 |
| Blade size | 210 mm |
| Motor | 1.6 kW, single phase, 220 V, 50 Hz |
| Speed | 4000 rpm |
| Maximum cutting depth at 90° | 70 mm |
| Maximum cutting depth at 45° | 45 mm |
| Supplied with | 3 blades; installation and operation manuals; service manual with circuit/system schematics (English) |
Scope of supply and ordering
The listing covers the portable circular saw with three blades and its manuals, supplied by JaincoLab. Lead time and packing depend on the order size and are confirmed when we quote.
Frequently asked questions
How deep can it cut?
Up to 70 mm at 90° and 45 mm at a 45° bevel.
What is supplied with the saw?
Three blades, installation and operation manuals and a service manual with circuit and system schematics, in English.
Related products
See the woodworking workshop machine range for other items in this family.
Request a quote
Use the contact page to ask for a quotation on the Portable Circular Saw, giving the SKU JA-WWM-8668 and the quantity. For tender or project supply, see our tenders page.
