Microprocessor pH-EC Meter
Product Code : JA-CM-2188
The Microprocessor pH-EC Meter (SKU JA-CM-2188) measures pH, electrical conductivity and temperature on one bench instrument with a backlit two-line display. This microprocessor pH EC meter recognises 4.00, 7.00 and 9.20 pH buffers, ranges conductivity automatically and stores up to 90 readings for printing. It is supplied by JaincoLab to soil, water and process laboratories and to college chemistry departments.
Specifications
The meter reads 0 to 14.00 pH at 0.01 pH resolution and ±0.01 pH ±1 digit accuracy, conductivity from 0-20 µS up to 0-200 mS at ±0.5% FS ±1 digit, and temperature from 0 to 100 °C at 0.1 °C resolution.
| Product | Microprocessor pH-EC Meter |
| SKU | JA-CM-2188 |
| pH | 0 to 14.00 pH; resolution 0.01 pH; accuracy ±0.01 pH ±1 digit |
| Auto buffer recognition | 4.00, 7.00 and 9.20 pH |
| Conductivity | 0-20 and 0-200 µS, 0-2, 0-20 and 0-200 mS, automatic ranging; resolution 0.01 µS; accuracy ±0.5% FS ±1 digit |
| Temperature | 0 to 100 °C; resolution 0.1 °C |
| Cell constant | Adjustable, 0.05 to 10.5 |
| Temperature compensation | Automatic or manual; 0-100 °C for pH, 0-50 °C for conductivity |
| Temperature coefficient | Adjustable, 0.1 to 4.0% (conductivity) |
| Display | 16 x 2 line alphanumeric LCD, backlit |
| Sample memory | Up to 90 readings, retained when switched off |
| Keyboard | 8 soft-touch membrane keys |
| Printer interface | Dot matrix printer with Centronics interface |
| Power | 230 V ±10% AC, 50 Hz |
| Dimensions (L x B x H) | Instrument 285 x 190 x 90 mm approx.; packing box 335 x 305 x 265 mm approx. |
| Weight | Instrument 2.5 kg approx.; boxed 3.5 kg approx. |
| Accessories listed | pH combination electrode, pH buffer tablets (4.00 and 7.00), conductivity cell, temperature probe, electrode stand, mains lead, operation manual, dust cover |
Applications of the microprocessor pH EC meter
Measuring pH and conductivity on the same sample with stored, printable results makes the meter practical for laboratories that report both values for water, soil extracts and process liquids.
- Soil and agricultural sample testing
- Boiler feed water, water works and purification plant checks
- Swimming pool water monitoring
- Chemical, pharmaceutical, fertiliser, refinery and brewery laboratories
- pH and conductometric practicals in college chemistry laboratories
Scope of supply and ordering
The listing covers the microprocessor pH-EC meter with the accessories listed in the table. A printer is not included in the listed accessories. Accessories, spares and quantities are confirmed on the quotation.
Minimum order quantity, lead time and packing are confirmed on each quotation for the number of meters and the delivery destination. JaincoLab supplies single meters and sets for college laboratories, testing laboratories and tender orders.
Frequently asked questions
Which pH buffers are recognised?
The meter recognises 4.00, 7.00 and 9.20 pH buffers automatically.
What conductivity range does it cover?
From 0-20 µS up to 0-200 mS in automatically selected ranges.
How many readings can it store?
Up to 90 readings, which stay in memory when the meter is switched off.
