Inverted Fluorescence Microscope
Product Code : JA-M-1011
The Inverted Fluorescence Microscope (SKU JA-M-1011) is an inverted microscope for cell cultures that combines long working distance plan achromatic objectives with matching PHP2 phase contrast objectives, all corrected for 1.2 mm cover glass such as culture vessel bases. An ultra long working distance condenser with phase contrast gives 55 mm of working space, and the magnification runs from 100x to 400x. Cell biology and biotechnology laboratories use this inverted fluorescence microscope for culture work.
Specifications
The listing gives 100x to 400x magnification, wide field 10x eyepieces, LWD plan achromatic 10x/0.25, 25x/0.4 and 40x/0.6 objectives, the same three powers as PHP2 phase contrast objectives, an ultra long working distance phase condenser with 55 mm working distance and a mechanical stage.
| Product | Inverted Fluorescence Microscope |
| SKU | JA-M-1011 |
| Magnification | 100x to 400x |
| Eyepieces | Wide field 10x |
| Objectives | LWD plan achromatic 10x/0.25, 25x/0.4, 40x/0.6 (cover glass 1.2 mm) |
| Phase contrast objectives | LWD plan achromatic 10x/0.25 PHP2, 25x/0.4 PHP2, 40x/0.6 PHP2 (cover glass 1.2 mm) |
| Condenser | Ultra long working distance, with phase contrast; working distance 55 mm |
| Stage | Mechanical stage |
Applications of the inverted fluorescence microscope
The microscope is used to view living cells through the base of flasks and dishes: bright field and phase contrast objectives cover unstained cells, and fluorescence observation is added with the illuminator and filter set agreed on the quotation.
- Phase contrast observation of cultured cells
- Checking cell growth in flasks and dishes
- Fluorescence work with the agreed filter set
- Cell biology and biotechnology practicals
- Postgraduate research training
Scope of supply and ordering
One unit is one inverted microscope with the listed eyepieces, six objectives, phase condenser and mechanical stage. The fluorescence illuminator, filter cubes, head type, accessories and quantities are confirmed on the quotation.
Each quotation states the minimum order quantity, the lead time and the packing for the quantity requested and the destination. JaincoLab handles bulk school and college orders and tender supplies, and ships to buyers in Africa, the Middle East and South and South-East Asia.
Frequently asked questions
Which objectives are supplied?
LWD plan achromatic 10x, 25x and 40x objectives and the same powers as PHP2 phase contrast objectives, all for 1.2 mm cover glass.
What is the condenser working distance?
The ultra long working distance phase condenser has a working distance of 55 mm.
Which fluorescence filters are included?
The fluorescence light source and filter sets are not given in the product data and are confirmed on the quotation.
Related products
- Inverted Phase Contrast Microscope
- Inverted Microscope
- Advanced Inverted Tissue Culture Microscope
- Inverted Tissue Culture Microscope
See the complete microscopes range for further models and spare parts.
Request a quote
Ask for a quotation on the Inverted Fluorescence Microscope (JA-M-1011) through the JaincoLab contact page, giving the quantity required and the delivery destination. Institutions and contractors buying under a tender can also reach us via the tenders page.
