Freezing Microtome
Product Code : JA-ELA-5488
The Freezing Microtome (SKU JA-ELA-5488) is a sectioning instrument made by JaincoLab for cutting thin to semi-thin sections of fresh tissue frozen with a carbon dioxide freezing attachment. The same method cuts semi-thin sections from industrial materials such as textiles, paper, leather, soft plastics, rubber, powders, pastes and food products. A table clamp fixes it to the edge of any standard laboratory table.
Specifications
The section range, freezing stage and feed listed for the freezing microtome are below.
| Product | Freezing Microtome |
| SKU | JA-ELA-5488 |
| Freezing | Carbon dioxide freezing attachment |
| Freezing stage | 35 mm diameter |
| Section thickness | 5 to 40 microns, in 5 micron steps |
| Total feed excursion | 25 mm |
| Mounting | Table clamp for the side of a standard table |
Materials sectioned
Freezing with carbon dioxide makes the material firm enough to cut without paraffin embedding, so fresh tissue can be sectioned quickly, and fats and enzymes that paraffin processing removes are kept in the section.
- Fresh frozen biological tissue in histology and botany practicals
- Textiles, paper and leather
- Soft plastics and rubber
- Powders, pastes and food products
Scope of supply and ordering
The listing covers the microtome with its table clamp and carbon dioxide freezing arrangement; the knife, gas cylinder connection, quantity and packing are confirmed on the quotation.
Frequently asked questions
What section thickness can it cut?
From 5 to 40 microns, in steps of 5 microns.
How is the specimen frozen?
With a carbon dioxide freezing attachment on the 35 mm freezing stage.
How is it fixed to the bench?
By a clamp that fits the side of any standard table.
How far can the specimen be fed?
The total feed excursion is 25 mm.
