Force Table
Product Code : JA-ELA-5326
The Force Table (SKU JA-ELA-5326) is used to verify the laws of the triangle, parallelogram and polygon of forces. It has a machined aluminium table 40 cm in diameter whose raised rim carries a scale graduated through 360 degrees, mounted on a vertical rod with a levelling base. A ring at the centre is held by cords passing over four pulleys on the rim. JaincoLab makes it complete with four pulleys, four weight hangers and twelve weights.
Specifications
The force table has a 40 cm machined aluminium top with a 360 degree scale on the raised rim, a vertical support rod on a base with levelling screws, a central ring on cords, and the pulleys, hangers and weights listed below.
| Product | Force Table |
| SKU | JA-ELA-5326 |
| Table | Machined aluminium, 40 cm diameter |
| Scale | Raised rim graduated through 360 degrees |
| Support | Vertical rod on a base with levelling screws |
| Body under study | Central ring on cords over four pulleys |
| Included | 4 pulleys, 4 weight hangers, 12 weights |
| Weights | 2 x 10 g, 2 x 20 g, 4 x 50 g, 4 x 100 g |
Experiments with the force table
The force table is used to balance three or four forces acting on a central ring, so students can measure their directions on the degree scale and verify the triangle, parallelogram and polygon laws of forces.
- Parallelogram law of forces
- Triangle and polygon laws of forces
- Vector addition and resolution of forces
- Equilibrium of concurrent forces in class 11 and B.Sc physics
Scope of supply and ordering
The listing covers one force table with four pulleys, four weight hangers and twelve weights (2 x 10 g, 2 x 20 g, 4 x 50 g, 4 x 100 g). Cords and spare weights are confirmed on the quotation. Accessories, spares and quantities are confirmed on the quotation.
Minimum order quantity, lead time and packing are confirmed on each quotation for the number of force tables and the delivery destination. Class sets and tender quantities are supplied.
Frequently asked questions
What laws does it verify?
The triangle, parallelogram and polygon laws of forces.
What size is the table?
40 cm in diameter, in machined aluminium with a 360 degree scale.
Which weights are included?
Twelve weights: 2 x 10 g, 2 x 20 g, 4 x 50 g and 4 x 100 g, with four hangers.
Related products
This apparatus is listed in the JaincoLab educational laboratory apparatus range.
Request a quote
To order the Force Table, send the number of force tables and delivery destination through the JaincoLab contact page or email [email protected], quoting SKU JA-ELA-5326. Buying under a laboratory tender? Use our tenders page.
