Digital Storage Oscilloscope 40MHz
Product Code : JA-DSO-1528
The 40 MHz digital storage oscilloscope is a two-channel bench instrument with an external trigger input, used in electronics, communication and physics laboratories to capture, store and measure signals. It has a rise time of 8.7 ns, vertical sensitivity from 2 mV/div to 5 V/div at 8-bit resolution, edge, video, pulse and delay triggering, and automatic voltage and time measurements (SKU JA-DSO-1528).
Specifications
Values listed for the 40 MHz model:
| Product | Digital Storage Oscilloscope 40MHz |
| SKU | JA-DSO-1528 |
| Bandwidth | 40 MHz |
| Channels | 2 + external trigger |
| Rise time | 8.7 ns |
| Equivalent sample rate | 50 GSa/s |
| Input impedance | 1 megohm // 13 pF |
| Input coupling | DC, AC, GND |
| Trigger types | Edge, video, pulse, delay |
| Trigger sources | CH1, CH2, Ext, Ext/5, Ext (50 ohm) |
| Acquisition modes | Auto, normal, single |
| Horizontal accuracy | ±0.01% |
| Vertical sensitivity | 2 mV/div to 5 V/div |
| Vertical resolution | 8 bit |
| Maximum input voltage | 400 V (DC + AC peak); 5 Vrms at 50 ohm |
| Automatic measurements | Vpp, Vamp, Vrms, Vmin, Vtop, Vbase, Vavg, frequency, period, rise time, fall time, +width, -width, overshoot, preshoot, +duty, -duty |
| Maths functions | +, -, x, ÷ and FFT |
Uses of the 40 MHz digital storage oscilloscope
The listed functions support:
- Capturing repetitive and single-shot signals in the auto, normal and single acquisition modes
- Reading amplitude, frequency, period, rise and fall times and duty cycle from the automatic measurements
- Viewing the frequency content of a signal with the FFT maths function
- Holding video and pulse signals steady on screen with the video and pulse trigger types
Scope of supply and ordering
The listing covers the 40 MHz two-channel digital storage oscilloscope with the specifications above, supplied by JaincoLab; accessories included with the unit are itemised on the quotation. Quantities, packing and lead time are confirmed on the quotation.
Frequently asked questions
What is the rise time of the 40 MHz model?
8.7 ns, with a vertical sensitivity range of 2 mV/div to 5 V/div at 8-bit vertical resolution.
Which trigger types and sources does it offer?
Edge, video, pulse and delay triggering, taken from CH1, CH2, the external input, Ext/5 or the 50 ohm external input.
What maximum input voltage is listed?
400 V (DC plus AC peak), and 5 Vrms where the 50 ohm input is used.
