Digital Storage Oscilloscope
Product Code : JC-E-1536
This digital storage oscilloscope listing covers dual-channel DSOs in 100 MHz, 200 MHz and 300 MHz bandwidth versions, each with 2 GSa/s real-time sampling, a 24k memory depth and a colour TFT LCD. The higher bandwidths suit faster signal work in electronics and communication labs, with six trigger modes, FFT on a split screen and a waveform recorder (SKU JC-E-1536).
Specifications
Data given for the range:
| Product | Digital Storage Oscilloscope |
| SKU | JC-E-1536 |
| Bandwidth versions | 100 MHz, 200 MHz, 300 MHz |
| Channels | 2 |
| Real-time sampling | 2 GSa/s |
| Memory depth | 24k |
| Display | Colour TFT LCD |
| Triggering | Edge, pulse, video, slope, alternative and delay modes |
| Ports | Front and back USB host/device; GPIB |
| Measurement functions | 32 automatic parameters; manual, track and auto cursor modes |
| Additional functions | Digital filter, waveform recorder, pass/fail testing, FFT split-screen display, multilingual menus and online help |
Scope of supply and ordering
The listing covers one dual-channel digital storage oscilloscope in the 100, 200 or 300 MHz version you choose, supplied by JaincoLab. Quantities, packing and lead time are confirmed on the quotation.
Frequently asked questions
Which bandwidth versions are listed?
100 MHz, 200 MHz and 300 MHz, all dual-channel with 2 GSa/s sampling and a 24k memory depth.
How are waveforms analysed on screen?
With 32 automatic measurement parameters, cursors in manual, track or auto mode, a digital filter and an FFT view beside the channel waveform.
How does it connect to a computer?
Through the USB host/device ports on the front and back, or the GPIB interface.
