Coil turns (500)
.jpg)
Product Code : JA-ETE-7701
The JaincoLab 500 turn transformer coil (SKU JA-ETE-7701) is a mid-range coil for building both step-up and step-down transformer ratios. It fits the common U-core and clamps assembly with the other coils of the range, so students can change one coil and see the effect on the output at once. For work from 230 V mains, it is paired with the 1000-turn Mains Coil. Schools and colleges use it in transformer and induction practicals.
Specifications
This coil has 500 turns and fits the U-core and clamps assembly shared by the whole coil range. The product data notes that it is not the mains coil: for connection to 230 V mains, the 1000-turn Mains Coil is required.
| Product | Coil turns (500) |
| SKU / Product code | JA-ETE-7701 |
| Number of turns | 500 |
| Core | Common U-core and clamps assembly |
| Transformer ratios | Step-up and step-down |
| Mains connection | Use the 1000-turn Mains Coil for 230 V |
Applications of the 500 turn transformer coil
With a turn count in the middle of the range, this coil can act as either primary or secondary. It is used for:
- Step-down demonstrations as the secondary of the 1000-turn Mains Coil (2:1 ratio)
- Step-up work with the 50, 100 or 200-turn coils as primary
- Verifying that the voltage ratio follows the turns ratio
- Transformer practicals in senior-secondary and undergraduate physics
Scope of supply and ordering
This listing covers one 500-turn coil, SKU JA-ETE-7701. The U-core and clamps and the other coils are listed separately and can be quoted together. Accessories, spares and quantities are confirmed on the quotation.
MOQ, lead time and packing are confirmed on each quotation for the quantity and the destination. We supply individual coils and full class sets to schools, colleges and tender contractors.
Frequently asked questions
Can the 500-turn coil be connected to mains?
No. For connection to 230 V mains, the 1000-turn Mains Coil is required; the 500-turn coil is then used as the secondary.
What ratios can I build with it?
Both step-up and step-down ratios, by pairing it with lower or higher-turn coils of the range on the U-core.
Which core does it fit?
The common U-core and clamps assembly used by all the coils in the range.
