Brazilian Test Apparatus
Product Code : JA-RT-9844
The Brazilian Test Apparatus (SKU JA-RT-9844) is a rock mechanics test set for determining the indirect tensile strength of rock by loading a disc-shaped specimen across its diameter. A pair of loading jaws contacts the disc at diametrically opposite surfaces over an arc of about 10 degrees at failure. The apparatus tests specimens of 50 to 100 mm diameter with a thickness of half the diameter; the jaws supplied suit 50 mm specimens. It is supplied by JaincoLab for civil, mining and geology laboratories.
Specifications
The set comprises a pair of loading jaws for 50 mm diameter discs (jaws for other diameters are ordered separately), for specimens from 50 to 100 mm diameter with thickness equal to half the diameter, and plain platens for cube and circular specimens up to 50 mm; the loading jack capacity are not listed in the product data and are confirmed on the quotation.
| Product | Brazilian Test Apparatus |
| SKU | JA-RT-9844 |
| Test | Brazilian (indirect tensile strength) test |
| Specimen | Discs 50-100 mm diameter; thickness half the diameter |
| Jaws supplied | For 50 mm diameter specimens; other sizes ordered separately |
| Contact arc | About 10 degrees at failure |
| Platens | Plain platens for cube and circular specimens up to 50 mm |
Applications of the Brazilian test apparatus
Students place a rock disc between the curved jaws, load it to failure along its diameter and calculate the indirect tensile strength from the failure load and disc dimensions.
- Indirect tensile strength of rock discs
- Comparing tensile strength of different rock types
- Specimen preparation to half-diameter thickness
- Rock mechanics practicals in civil and mining engineering
- Geology and engineering geology courses
Scope of supply and ordering
This listing covers the Brazilian test jaws for 50 mm specimens and the plain platens described. Accessories, spares and quantities are confirmed on the quotation. Jaws for other diameters and the loading frame are confirmed on the quotation.
MOQ, lead time and packing for the Brazilian Test Apparatus are confirmed on each quotation for the quantity and delivery destination. Single units for one laboratory and complete sets for institutions or projects are both supplied.
Frequently asked questions
Which specimen sizes can be tested?
Discs of 50 to 100 mm diameter with a thickness of half the diameter.
Which jaws are supplied?
Jaws for 50 mm diameter specimens; jaws for other diameters must be ordered.
What property does it measure?
Indirect tensile strength of rock.
