Biological Microscope
Product Code : JA-M-949
The Biological Microscope (SKU JA-M-949) is an infinity-corrected laboratory microscope with a listed total magnification of 40x to 1500x, infinity achromatic 4x, 10x, 40x and 100x objectives on an inverted roller-bearing quadruple nosepiece and high-point WF 10x eyepieces. It has coaxial coarse and fine focusing with tension adjustment and 2 micron fine divisions, a 50 x 75 mm right-hand coaxial stage with 0.1 mm scale, and a monocular, binocular or trinocular head at 30 degrees. JaincoLab manufactures this infinity biological microscope.
Specifications
Listed specification: 40x-1500x total; inverted quadruple roller-bearing nosepiece; WF 10x high-point eyepieces; infinity achromatic 4x, 10x, 40x and 100x; coaxial focus with tension, 20 mm range, 2 micron fine division; 50 x 75 mm stage travel with 0.1 mm scale; 30-degree heads rotating 360 degrees; illuminator.
| Product | Biological Microscope |
| SKU | JA-M-949 |
| Total magnification | 40x to 1500x, as listed |
| Nosepiece | Inverted quadruple, roller bearing |
| Eyepieces | High-point WF 10x |
| Objectives | Infinity achromatic 4x, 10x, 40x and 100x |
| Focusing | Coaxial coarse and fine with tension adjustment; range 20 mm; fine division 2 microns |
| Stage | Travel 50 x 75 mm, right-hand coaxial control, scale division 0.1 mm |
| Heads | Monocular, binocular or trinocular, inclined at 30 degrees, rotatable 360 degrees |
| Illumination | Illuminator without field diaphragm |
Applications of the infinity biological microscope
College and university teaching labs use it for routine biology and microbiology work, choosing the monocular head for student benches, the binocular for longer sessions or the trinocular for camera recording, with the 100x objective for bacteria and blood smears.
- Routine biology and microbiology teaching
- Blood smears and bacteria with the 100x objective
- Histology slide study
- Camera recording with the trinocular head
- College and university practical labs
Scope of supply and ordering
One unit is one biological microscope with the chosen head, four infinity objectives and WF 10x eyepieces. Optional accessories, spares and quantities are confirmed on the quotation.
MOQ, lead time and packing are stated on each quotation according to the order quantity and the delivery destination. Bulk orders for school laboratories, colleges and education programmes are supplied, and export consignments are shipped to buyers in Africa, the Middle East and South and South-East Asia.
Frequently asked questions
What magnification range is listed?
A total magnification of 40x to 1500x.
Which heads can be chosen?
Monocular, binocular or trinocular, inclined at 30 degrees and rotatable through 360 degrees.
How fine is the focusing?
Coaxial coarse and fine focusing with a 20 mm range and 2 micron fine divisions.
