Simple Pattern Sonometer
Product Code : JA-SW-7655
The Simple Pattern Sonometer (SKU JA-SW-7655) is a two-wire sonometer on a wooden resonance box 1140 mm long, 125 mm wide and 100 mm high. Two 50 N spring balances with hooks at one end and two wrest pins at the other hold two steel wires, 30 SWG and 1 metre long, and three bridges are supplied: one large bridge spanning both wires and two small bridges for the individual wires. JaincoLab supplies this simple pattern sonometer for string vibration practicals in schools and colleges.
Specifications
The Simple Pattern Sonometer has a wooden resonance box of 1140 × 125 × 100 mm, two 50 N spring balances with hooks and two wrest pins for tensioning, two 30 SWG steel wires 1 m long, and three bridges, one large and two small.
| Product | Simple Pattern Sonometer |
| SKU | JA-SW-7655 |
| Resonance box | Wooden, 1140 mm long, 125 mm wide, 100 mm high |
| Tensioning | Two 50 N spring balances with hooks at one end; two wrest pins at the other |
| Wires | Two steel wires, 30 SWG, 1 metre long |
| Bridges | Three: one large (spanning both wires) and two small (for the individual wires) |
Vibrating string experiments with the simple sonometer
With each wire tensioned by its own 50 N spring balance, students can compare two wires directly: they vary the length between bridges and the tension on the balance to verify the laws of vibrating strings, and tune a wire into resonance with a tuning fork to find the fork’s frequency.
- Verifying the relation between frequency and vibrating length
- Studying the effect of tension using the 50 N spring balances
- Comparing two wires side by side under different tensions
- Finding the frequency of a tuning fork by resonance
- Senior-secondary and college practicals on stationary waves
Scope of supply and ordering
Supplied with the resonance box, two 50 N spring balances, two wrest pins, two 30 SWG steel wires 1 m long and three bridges. Tuning forks are listed separately. Accessories, spares and quantities are confirmed on the quotation.
Minimum order quantity, lead time and packing are confirmed on each quotation according to the quantity and the delivery destination. JaincoLab supplies sonometers to individual schools, colleges and education programmes, and exports to Africa, the Middle East and South and South-East Asia.
Frequently asked questions
What size is the resonance box?
It is a wooden box 1140 mm long, 125 mm wide and 100 mm high.
Which wires are supplied?
Two steel wires, 30 SWG and 1 metre long.
How is tension applied?
Each wire runs from a wrest pin to one of two 50 N spring balances with hooks.
Which bridges are included?
Three bridges: one large bridge spanning both wires and two small bridges for the individual wires.
