Resistance Coil 100 Ohm
Product Code : JA-EE-7494
The Resistance Coil 100 Ohm (SKU JA-EE-7494) is a 100 ohm resistance unit made up as a block with 4 mm sockets, for adding a higher known resistance to circuits in basic electrical experiments. This 100 ohm resistance coil for school circuits keeps currents small in low-voltage practicals and connects straight to 4 mm plug leads instead of loose resistor wires. JaincoLab supplies it as part of a range of values.
Specifications
The Resistance Coil 100 Ohm gives 100 ohm of resistance in a block fitted with 4 mm sockets, replacing a simple resistor with a unit that plugs directly into 4 mm lead circuits; tolerance and power rating are confirmed on the quotation.
| Product | Resistance Coil 100 Ohm |
| SKU | JA-EE-7494 |
| Resistance | 100 ohm |
| Form | Resistance unit (block) |
| Connections | 4 mm sockets |
| Use | Adding a known resistance to circuits in basic electrical experiments |
Applications of the 100 ohm resistance coil
A 100 ohm coil is chosen when a circuit needs a larger known resistance, for example to limit current through an LED or meter, to build voltage dividers with smaller values, or to show how total resistance changes when high and low values are combined.
- Current limiting for LEDs and sensitive meters
- Voltage dividers combining 100 ohm with lower values
- Series and parallel combinations of high and low resistances
- Charging and discharging capacitors through a known resistance
- Class sets of resistance units for circuit practicals
Scope of supply and ordering
Each listing is one 100 ohm resistance unit with 4 mm sockets. Other values, leads and meters are separate items. Accessories, spares and quantities are confirmed on the quotation.
MOQ, lead time and packing are confirmed per quotation for the quantity, values and destination. JaincoLab supplies resistance units to schools, colleges and education projects, including export orders to Africa, the Middle East and South and South-East Asia.
Frequently asked questions
What resistance does the coil provide?
It provides 100 ohm.
How does it connect to a circuit?
Through 4 mm sockets on the block, using standard 4 mm plug leads.
Is it the highest value in the range?
It is the highest of the listed resistance coils; 1, 2, 5, 10, 20 and 50 ohm units are also listed.
Related products
The full set of resistance coils and rheostats is in electricity equipment from JaincoLab, a physics lab equipment manufacturer in India.
Request a quote
To order the Resistance Coil 100 Ohm, send the quantity and delivery destination through the JaincoLab contact page or email [email protected]. Buying under a laboratory tender? Use our tenders page.
