Platinum Resistance Thermometer
Product Code : JA-ELA-5462
The Platinum Resistance Thermometer (SKU JA-ELA-5462) is made by JaincoLab for measuring temperature from the electrical resistance of pure platinum wire. A platinum resistance thermometer, one kind of resistance temperature detector (RTD), uses the fact that the resistance of platinum rises steadily with temperature. In this instrument, platinum wire of 2.8 ohm is wound on a mica frame and enclosed in a glass tube, with two platinum leads and two compensating leads brought out to terminals.
Specifications
The sensing element is 2.8 ohm platinum wire on a mica frame inside a glass tube (listed as Pyrex glass), with platinum and compensating leads.
| Product | Platinum Resistance Thermometer |
| SKU | JA-ELA-5462 |
| Sensor | Pure platinum wire, 2.8 ohm |
| Former | Mica frame |
| Leads | Two platinum wire leads and two compensating lead terminals |
| Enclosure | Glass tube (listed as Pyrex glass) |
| Principle | Resistance of platinum changes with temperature |
Experiments with the platinum resistance thermometer
- Measuring temperature with a Callendar and Griffiths bridge or another resistance bridge
- Finding the temperature coefficient of resistance of platinum
- Calibrating at fixed points such as melting ice and boiling water
- Resistance thermometry practicals in B.Sc. physics
Scope of supply and ordering
Each thermometer is supplied with its compensating leads as described; a resistance bridge, galvanometer and quantity are confirmed on the quotation with packing and lead time.
Frequently asked questions
What is the resistance of the platinum element?
The platinum wire has a resistance of 2.8 ohm.
Why are compensating leads provided?
They let the resistance of the connecting leads be balanced out in the bridge, so only the change in the platinum coil is measured.
What is the element wound on?
A mica frame, enclosed in a glass tube.
