Orbital Shaking Incubator
Product Code : JA-I-2067
The Orbital Shaking Incubator (SKU JA-I-2067) combines controlled incubation with orbital shaking driven by a geared motor, for tissue culture, fermentation, enzyme reaction and growth studies. JaincoLab makes this orbital shaking incubator with a stainless steel chamber, PID temperature control and a digital rpm meter and timer, for microbiology, biotechnology and pharmacy laboratories.
Specifications
The unit is triple walled, with a mild steel outer (painted or powder coated), a thick stainless steel inner, glass wool insulation, a plexiglass window, a fluorescent tube and an air circulation fan; temperature runs from ambient to 100 °C under a dual-display PID controller with ±0.5 °C accuracy.
| Product | Orbital Shaking Incubator |
| SKU | JA-I-2067 |
| Construction | Triple walled; MS outer painted or powder coated; SS inner; glass wool insulation |
| Viewing | Plexiglass window |
| Lighting | Fluorescent tube, door or panel operated |
| Temperature range | Ambient to 100 °C |
| Temperature control | Dual-display microprocessor PID, ±0.5 °C |
| Air circulation | Fan |
| Shaking | Orbital, geared motor, 30 to 250 rpm |
| Tray | Stainless steel with lotus-type flask clamps |
| Capacity | 16 flasks of 50 ml |
| Displays | Digital rpm meter; digital timer up to 999 min |
Applications of the orbital shaking incubator
Orbital shaking at a controlled temperature keeps cultures aerated and mixed, which liquid cultures, fermentation studies and enzyme reactions need for consistent growth and results.
- Growing liquid microbial cultures in flasks
- Fermentation and growth studies
- Enzyme reaction studies at controlled temperature
- Tissue culture work in biotechnology laboratories
Scope of supply and ordering
The listing covers the orbital shaking incubator with its stainless steel tray and clamps for 16 x 50 ml flasks, PID controller, rpm meter and timer. Clamps for other flask sizes are confirmed on the quotation. Accessories, spares and quantities are confirmed on the quotation.
Minimum order quantity, lead time and packing are confirmed on each quotation for the number of units and the delivery destination. JaincoLab supplies single incubators and multiple units for colleges and research laboratories.
Frequently asked questions
What shaking speed range does it have?
30 to 250 rpm, shown on a digital rpm meter.
What temperature range does it cover?
Ambient to 100 °C, with a dual-display PID controller of ±0.5 °C accuracy.
How many flasks does it hold?
The tray takes 16 flasks of 50 ml in lotus-type clamps.
Related products
Bacteriological and BOD incubators are listed in the JaincoLab laboratory incubator range.
Request a quote
To order the Orbital Shaking Incubator, send the flask sizes, quantity and delivery destination through the JaincoLab contact page or email [email protected]. Institutions and contractors buying under a tender can also reach us via the tenders page.
