Microprocessor Potentiometer
Product Code : JA-PM-2181
The Microprocessor Potentiometer (SKU JA-PM-2181) measures millivolts and temperature for potentiometric work, guiding the user through each measurement with on-screen prompts. It comes with a magnetic stirrer and four electrodes, so it is ready for ORP and acid-base titrations. This microprocessor potentiometer is supplied by JaincoLab to chemistry, pharmacy and university laboratories.
Specifications
The instrument reads 0 to ±1999.9 mV and 0 to 100 °C with resolutions of 0.1 mV and 0.1 °C and accuracies of ±0.1 mV ±1 digit and ±0.1 °C, has input impedance above 10^12 ohm, a 16 x 2 line alphanumeric LCD, 8 membrane keys and memory for 90 samples.
| Product | Microprocessor Potentiometer |
| SKU | JA-PM-2181 |
| mV range | 0 to ±1999.9 mV; resolution 0.1 mV; accuracy ±0.1 mV ±1 digit |
| Temperature range | 0 to 100 °C; resolution 0.1 °C; accuracy ±0.1 °C |
| Input impedance | Above 10^12 ohm |
| Display | 16 x 2 line alphanumeric LCD |
| Keys | 8 soft-touch membrane keys |
| Memory | 90 samples, retained when switched off |
| Printer | Port for a dot-matrix printer with Centronics interface |
| Stirrer | Magnetic stirrer with variable speed; power from rear socket |
| Electrodes | Reference, platinum, silver and glass |
Applications of the microprocessor potentiometer
Potentiometric titration follows the change in electrode potential as titrant is added, which locates the end point without an indicator and suits coloured or turbid solutions.
- Acid-base titrations with the glass electrode
- ORP and redox titrations with the platinum electrode
- Precipitation titrations with the silver electrode
- Pharmaceutical analysis and university chemistry practicals
Scope of supply and ordering
The listing covers the microprocessor potentiometer with magnetic stirrer and the four electrodes. A printer, if required, is quoted separately. Accessories, spares and quantities are confirmed on the quotation.
Minimum order quantity, lead time and packing are confirmed on each quotation for the number of units and the delivery destination. JaincoLab supplies single units and sets for college and industrial laboratories.
Frequently asked questions
What does it measure?
Millivolts from 0 to ±1999.9 mV and temperature from 0 to 100 °C.
Which electrodes come with it?
Reference, platinum, silver and glass electrodes, with a magnetic stirrer.
Can results be stored?
Yes. It stores 90 samples and has a port for a dot-matrix printer.
