Dual Range Voltmeter
Product Code : JA-M-7919
The Dual Range Voltmeter (SKU JA-M-7919) is a moving coil, DC-only meter with two ranges, used to measure potential difference in school and college electricity practicals. It is listed in three range pairs, 0-1 V/5 V, 0-5 V/10 V and 0-5 V/15 V, with a 60 mm scale and 4 mm socket terminals in a 125 x 80 x 80 mm case. This dual range moving coil DC voltmeter is manufactured in India by JaincoLab, which also lists single range models.
Specifications
The voltmeter is a moving coil DC instrument with 4 mm socket terminals, a 60 mm scale length and a 125 x 80 x 80 mm case, offered in 0-1/5 V, 0-5/10 V and 0-5/15 V dual-range versions.
| Product | Dual Range Voltmeter |
| SKU | JA-M-7919 |
| Movement | Moving coil |
| Measurement | DC only |
| Dual ranges listed | 0-1 V/5 V, 0-5 V/10 V, 0-5 V/15 V |
| Scale length | 60 mm |
| Terminals | 4 mm sockets |
| Size | 125 x 80 x 80 mm |
Applications of the dual range moving coil DC voltmeter
The dual range voltmeter is connected across components in DC circuits, and its second range lets students start on the higher range and switch down for a finer reading without changing meters.
- Ohm's law and V-I characteristic practicals
- Measuring the voltage of cells and batteries
- Potential difference across series and parallel resistors
- Meter bridge, potentiometer and resistivity experiments
- Diode and simple electronics circuits at low DC voltage
Scope of supply
Each unit is one dual range DC voltmeter in the range pair ordered. Leads, accessories, spares and quantities are confirmed on the quotation.
Packing, MOQ and lead time
The quotation confirms MOQ, packing and lead time for the number of meters, the range pairs and the delivery destination. JaincoLab supplies class sets of meters for schools and colleges and bulk orders for education projects and export buyers in Africa, the Middle East and South and South-East Asia.
Frequently asked questions
Which range pairs are available?
0-1 V/5 V, 0-5 V/10 V and 0-5 V/15 V.
Can it measure AC voltage?
No. It is a moving coil meter for DC only.
What are the scale length, size and terminals?
It has a 60 mm scale, measures 125 x 80 x 80 mm and has 4 mm socket terminals.
Is a single range version available?
Yes. Single range moving coil voltmeters are listed separately in the same Measurement range.
What should a quotation request include?
Send the SKU JA-M-7919, the range pair and quantity of each, and the delivery destination.
