Coil turns (200)
.jpg)
Product Code : JA-ETE-7697
The JaincoLab 200 turn transformer coil (SKU JA-ETE-7697) belongs to a modular set of coils, from 50 to 2000 turns, that are built into transformer and electromagnetism demonstrations around one common U-core. Its two front-mounted 4 mm sockets are clearly labelled, so students can identify the coil and wire it quickly. Schools and colleges use it as a secondary or primary coil in low-voltage transformer practicals.
Specifications
This coil has 200 turns and two front-mounted 4 mm sockets that are clearly labelled for quick identification. It fits the common U-core shared by all coils in the 50 to 2000-turn set, as listed in the product data.
| Product | Coil turns (200) |
| SKU / Product code | JA-ETE-7697 |
| Number of turns | 200 |
| Terminals | Two front-mounted 4 mm sockets, clearly labelled |
| Coil set | Modular set, 50 to 2000 turns |
| Core | Common U-core assembly |
Applications of the 200 turn transformer coil
Pairing coils of different turn counts on the U-core shows students how a transformer changes voltage. This coil is used for:
- Investigating the relationship between turns ratio and voltage ratio
- Building step-up and step-down transformers with the other coils
- Electromagnet and induction demonstrations on the U-core
- Senior-secondary and B.Sc practicals on electromagnetism
Scope of supply and ordering
This listing covers one 200-turn coil, SKU JA-ETE-7697. The U-core and clamps and the other coils are listed separately and can be combined on one order. Accessories, spares and quantities are confirmed on the quotation.
MOQ, lead time and packing are confirmed on each quotation according to quantity and destination. Coils are supplied singly or as class sets for school, college and tender orders.
Frequently asked questions
How is the coil connected?
Through two front-mounted 4 mm sockets, clearly labelled for quick identification.
Which core does it use?
It fits the common U-core used by every coil in the modular 50 to 2000-turn set.
Can I buy a complete set of coils?
Yes. Coils of different turn counts, the U-core and clamps can be quoted together as a set.
