Clipping and Clamping Circuit Apparatus
Product Code : JA-VOVLACOS-1112
The Clipping and Clamping Circuit Apparatus (SKU JA-VOVLACOS-1112) is used to study how positive and negative clipping and clamping change a sine wave. Two fixed-output DC supplies, connected in series with diodes, set the clipping and clamping levels. The circuits are printed on the panel, the components sit inside the enclosure, and the connections are brought out to terminals. The listing names an audio function generator (type TE-93) and a CRO (type TE-97) as optional accessories for the input signal and display.
Specifications
The listing gives these details:
| Product | Clipping and Clamping Circuit Apparatus |
| SKU | JA-VOVLACOS-1112 |
| DC supplies | Two, fixed output, in series with diodes |
| Panel | Clipping and clamping circuits printed |
| Construction | Components in enclosure, connections on terminals |
| Optional accessories | Audio function generator TE-93, CRO TE-97 |
| Size | 8 x 6 x 4 in |
Scope of supply and ordering
The function generator and CRO are optional and are quoted separately if needed. Quantities and packing are confirmed on the quotation.
Frequently asked questions
What does the clipping and clamping apparatus demonstrate?
The effect of positive and negative clipping and clamping on a sine wave.
What is needed besides the apparatus?
A sine-wave source and a CRO; the listing names an audio function generator TE-93 and a CRO TE-97 as optional accessories.
