Brass Coaxial Clamp
Product Code : JA-LS-5015
The Brass Coaxial Clamp (SKU JA-LS-5015) is a spring-controlled laboratory clamp made by JaincoLab whose jaws are opened and closed by a coaxial brass nut, holding apparatus up to 75 mm in diameter. The moulded jaws are epoxy-coated alloy, either asbestos sleeved or rubber covered; the brass casting is fully chrome plated and the mild steel rod is 12 in x 3/8 in, chrome plated.
Specifications
The listing gives the rod size in inches and the grip in millimetres.
| Product | Brass Coaxial Clamp |
| SKU | JA-LS-5015 |
| Jaw adjustment | Coaxial brass nut, spring controlled |
| Grip | Up to 75 mm diameter |
| Jaws | Moulded alloy, epoxy coated; asbestos sleeved or rubber covered |
| Body | Brass casting, all chrome plated |
| Rod | Mild steel, 12 in x 3/8 in, chrome plated |
Scope of supply and ordering
State whether rubber-covered or asbestos-sleeved jaws are required; quantities and packing are confirmed on the quotation. Handling, use and disposal must follow the regulations that apply to this material in the destination country.
Frequently asked questions
How are the jaws adjusted?
With a coaxial brass nut; the jaws are spring controlled.
What is the largest diameter it holds?
Up to 75 mm.
What rod is fitted?
A chrome-plated mild steel rod, 12 in long and 3/8 in in diameter.
Related products
Coaxial and universal clamps are in the JaincoLab lab supplies range.
Request a quote
Send your jaw-covering choice and quantity for the Brass Coaxial Clamp (JA-LS-5015) through our contact page. Institutions and contractors buying under a tender can also reach us via the tenders page.
