2 Channel Digital Strain Meter
Product Code : JA-MI-4919
The 2 Channel Digital Strain Meter (SKU JA-MI-4919) is a portable, direct-reading digital strain meter for energising electrical resistance strain gauges and reading the bridge output on a 5-digit LCD. It measures up to 20,000 microstrain with a resolution of 1 digit, works with standard foil gauges in half or full bridge circuits with 1, 2 or 4 active gauges, and can read force directly from gauged force transducers. It runs on mains or a rechargeable Ni-MH battery for field use. It is supplied by JaincoLab for structures and strength-of-materials laboratories.
Specifications
The meter reads up to 20,000 microstrain, or force in newtons with 1 N resolution, on a 5-digit LCD, has two channels with DC excitation, and offers an analogue output on one channel for dynamic work up to at least 10 Hz.
| Product | 2 Channel Digital Strain Meter |
| SKU | JA-MI-4919 |
| Channels | 2, DC excitation for static work |
| Range | Up to 20,000 microstrain |
| Resolution | 1 digit |
| Display | 5-digit LCD; strain or force (newtons x 1 N) |
| Bridge | Half or full bridge, 1, 2 or 4 active gauges |
| Dynamic output | Analogue output on one channel, up to at least 10 Hz |
| Expansion | Up to 18 inputs with the 16-channel expansion unit |
| Power | Mains operated with rechargeable Ni-MH battery; at least 8 hours use |
| Supply | 12 V for running or charging; single phase 100/240 V AC, 50/60 Hz |
Applications of the digital strain meter
A two-channel strain meter lets students read strain gauges on beams and structures directly in microstrain, or read force from a gauged transducer, without extra instruments.
- Strain measurement on beams, frames and trusses in structures laboratories
- Strength-of-materials experiments with foil strain gauges
- Reading force transducers and load cells
- Measuring the frequency and amplitude of dynamic actions through the analogue output
Scope of supply and ordering
The listing covers the two-channel digital strain meter. The 16-channel expansion unit and connecting cables are separate items. Accessories, spares and quantities are confirmed on the quotation.
Minimum order quantity, lead time and packing are confirmed on each quotation for the number of units and the delivery destination. Single meters and complete strain measurement sets for engineering laboratories and tenders are supplied.
Frequently asked questions
What range does it measure?
Up to 20,000 microstrain with a resolution of 1 digit.
Which gauge arrangements does it accept?
Standard foil gauges in half or full bridge circuits with 1, 2 or 4 active gauges, including gauges on force transducers.
Can it be used away from mains power?
Yes. It has a rechargeable Ni-MH battery giving at least 8 hours of use.
Can more channels be added?
Yes. With the 16-channel expansion unit it becomes an 18-channel system.
