150 MHz RF Signal Generator
Product Code : JA-SG-1545
The 150 MHz RF signal generator covers 100 kHz to 150 MHz in six bands, with third-harmonic output up to 450 MHz, internal 1 kHz and external 50 Hz to 20 kHz modulation, and a fixed 1 kHz audio output. A built-in frequency meter reads 10 Hz to 150 MHz, which suits RF circuit and receiver practicals in electronics and communication labs (SKU JA-SG-1545).
Specifications
Listed specifications:
| Product | 150 MHz RF Signal Generator |
| SKU | JA-SG-1545 |
| Frequency bands | A 100-300 kHz; B 300 kHz-1 MHz; C 1-3.2 MHz; D 3-10 MHz; E 10-35 MHz; F 32-150 MHz |
| Harmonic output | 3rd harmonic up to 450 MHz |
| Frequency accuracy | ± resolution ± 1 digit |
| RF output amplitude | 100 mVrms (at 35 MHz) |
| Amplitude control | 0 dB / 20 dB and fine tune |
| Modulation | Internal 1 kHz; external 50 Hz to 20 kHz (below 1 Vrms) |
| Audio output | 1 kHz fixed, minimum 1 Vrms |
| Frequency meter range | Low 10 Hz to 10 MHz; high 10 MHz to 150 MHz |
| Meter input sensitivity | Less than 50 mV |
| Meter maximum input | Less than approx. 3 Vrms |
| Meter accuracy | Low range 1 Hz; high range 10 Hz |
| Operating temperature | 0 to 40 °C |
Uses of the RF signal generator
The listed functions support:
- A signal source for RF amplifier, oscillator and receiver practicals from 100 kHz to 150 MHz
- Modulated test signals from the internal 1 kHz source or an external 50 Hz to 20 kHz input
- Reading the frequency of an external signal on the built-in frequency meter
Scope of supply and ordering
The listing covers the 150 MHz RF signal generator with its built-in frequency meter, supplied by JaincoLab. Order quantity, packing and delivery time are set out on each quotation.
Frequently asked questions
What frequency range does it cover?
100 kHz to 150 MHz in six bands (A to F), with third-harmonic output up to 450 MHz.
What modulation is available?
Internal modulation at 1 kHz, or external modulation from 50 Hz to 20 kHz at less than 1 Vrms.
What can the built-in frequency meter read?
10 Hz to 10 MHz on the low range and 10 MHz to 150 MHz on the high range, with an input sensitivity of less than 50 mV.
